Pulsar Merger LRF XP50 Thermal Binoculars
*UK Users Only*
Classically-Shaped Thermal Imaging Binoculars
Pulsar has introduced new thermal imaging binoculars with their Pulsar Merger LRF XP50 thermal binoculars. These cutting-edge thermal spotter binoculars combine the classic binocular shape with the latest Pulsar thermal technology offerings.
These Pulsar thermal binoculars include a powerful 640x480, 17µm <25mK NETD thermal imaging sensor and fast aperture F50/1.0 germanium lens to produce exceptional detection capabilities of up to 1800m and perfect detail recognition with a sharp, richly contrasted image. Plus an exact laser rangefinder (LRF), measuring up to 1000m!
The comfortable pulsar Merger LRF XP50 binoculars succeed the very popular Pulsar Accolade binoculars, with improvements in the lens speed, a better AMOLED screen (higher resolution), and improved battery life.
Boasting a dual eyepiece, the Merger LRF XP50 binoculars have been designed to reduce eye fatigue over long periods of observation, whilst presenting a more natural and detailed view of observed objects, even in conditions with low-temperature contrast.
Includes FREE spare battery & Pulsar Cap!
Find our Pulsar Comparison Tool here
Product details
Key Features
- classic, comfortable binocular design with natural button placement
- powerful 640x480, 17µm <25mK NETD thermal imaging sensor
- fast aperture F50/1.0 germanium lens
- detection range up to 1800m
- Laser Rangefinder measuring up to 1000m
- Up to 10-hour battery life
- 1024x768 resolution AMOLED Screen
- Stream vision 2 capabilities (for live streaming and more)
- 2.5-20x magnification range
- 8 colour palettes
Specifications
| Main | |
| Sensor | 640x480 @ 17 µm (NETD <25 mK) |
| Objective lens | F50/1.0 |
| Magnification, x | 2.5 – 20 (x8 zoom) |
| Field of view (HxV), degrees / m@100m | 12.4x9.3 / 21.8x16.3 |
| Detection range, m | 1800 |
| Sensor | |
| Type | uncooled |
| Resolution, pixels | 640x480 |
| Pixel pitch, µm | 17 |
| NETD, mK | <25 |
| Frame rate, Hz | 50 |
| Optics | |
| Objective lens | F50/1.0 |
| Magnification, x | 2.5 – 20 |
| Field of view (HxV), degrees / m @ 100 m | 12.4x9.3 / 21.8x16.3 |
| Interpupillary distance adjustment, mm | 62 - 74 |
| Eye relief, mm | 15 |
| Display | |
| Type | AMOLED HD |
| Resolution, pixels | 1024x768 |
| Range Performance | |
| Detection range, m | 1800 |
| Laser Rangefinder | |
| Safety class for laser equipment according to IEC 60825-1:2014 | 1 |
| Wavelength, nm | 905 |
| Max. measuring range, m | 1000 |
| Measurement accuracy, m | ± 1 |
| Video Recorder | |
| Video / photo resolution, pixel | 1024x768 |
| Video / photo format | .mp4 / .jpg |
| Built-in memory, GB | 16 |
| Wi-Fi | |
| Wireless Protocol | Wi-Fi |
| Wireless Standard | IEEE 802.11 b/g/n/ac (WPA) |
| Frequency, GHz | 2.4 / 5 |
| Environmental Characteristics | |
| Degree of protection, IP code (IEC60529) | IPХ7 (waterproof) |
| Operating temperature range, °С | -25 – +50 |
| Connections and Compatibilities | |
| Mount, type | 1/4" socket |
| Supported Application | Stream Vision 2 |
| Power Supply | |
| Output voltage, V | 3.7 |
| Battery type | Dual Li-Ion power system: APS 3 changeable battery (3.2 A·h) and built-in battery pack (4.0 A·h) |
| Capacity, mAh | 3200 (external) + 4000 (internal) |
| Operating time on battery pack (at t=22°C), h * | 9 |
| External power supply, V | 5 (USB Type C) |
| Weight & Size | |
| Body material | Magnesium alloy |
| Dimensions, mm | 196x143x76 |
| Weight, kg | 0.95 (batteries included) |
