Pulsar Merger LRF XT50 Thermal Binoculars
*UK Users Only*
High-Definition Pulsar XT50 Binoculars
Pulsar's Merger XT50 binoculars are the first thermal imaging binoculars from Pulsar featuring a cutting-edge 1280×1024, 12µm, <40mK NETD HD thermal sensor. With a powerful 50mm f1.0 objective lens and lossless pixel transfer, these Pulsar Binoculars deliver unmatched image clarity and long-range detection, revealing heat sources up to 2300m away. They offer truly stunning and precise thermal imagery at night and during the day, for when more detail is really matters.
The Merger XT50 binoculars excel in maintaining exceptional detail across its 2.0-16.0x magnification range, thanks to minimal image compression. Enhanced with built-in image stabilization and a range of digital functionalities—including a still image and video recorder, Stream Vision 2 compatibility, and a precision laser rangefinder—these binoculars ensure a superior observation experience without distractions. Perfect for long-range viewing, the Pulsar Merger XT50 sets a new standard in thermal imaging.
Find our Pulsar Comparison Tool here
Product details
Key Features
- FULL HD resolution 12 micron 1280px resolution sensor
- Premium magnesium alloy construction
- High quality F1.0 germanium lens system
- Super AMOLED eye displays
Specifications
| Microbolometer | |
| Type | uncooled |
| Resolution, Pixels | 1280 x 1024 |
| Pixel Pitch, µm | 12 |
| NETD, mK | < 40 |
| Frame Rate, Hz | 50 |
| Optical | |
| Lens, mm | F50 / 1.0 |
| Continuous Digital Zoom, x | 2 - 16 |
| Sensor | 1280x1024 @ 12 µm (NETD < 40 mK) |
| Objective Lens | F50 / 1.0 |
| Magnification, x | 2 - 16 |
| FOV (HxV) Degrees / m@100m | 17.5 x 14 / 30.7 x 24 |
| Detection Range | 2300 m |
| Digital Zoom | 2x/4x/8x |
| Minimum Focus Distance, m/y | 5 / 5.47 |
| Eye Relief, mm/inch | 15 / 0.59 |
| Exit Pupil Diameter, mm | 3.5 |
| Field of View (HxV), Degrees / m@100m | 17.5 / 30.7 |
| Diopter Adjustment, D | -5/+4 |
| Interpupillary Distance Adjustment, mm | 63-74 |
| Range of Detection (Deer Type Object), m/y | 2300 / 2515 |
| Display | |
| Type | AMOLED HD |
| Resolution, Pixels | 1280 x 960 |
|
| |
| Max. Measuring Range, m/y* | 1500 / 1640 |
| Measurement Accuracy, m | ± 1 |
| Safety Class for Laser Equipment according to IEC 60825-1:2014 | 1 |
| Wavelength, nm | 905 |
| Video Recorder | |
| Video / Photo Resolution, Pixel | 1280 x 960 |
| Video / Photo Format | .mp4 / .jpg |
| Built-in Memory, GB | 64 |
| Wi-Fi** | |
| Wireless protocol | Wi-Fi |
| Wireless Standard | IEEE 802.11 b/g/n/ac (WPA) |
| Frequency, Ghz | 2.4 / 5 |
| Environmental Characteristics | |
| Degree of Protection IP Code (IEC60529) | IPX7 (waterproof) |
| Operating Temperature Range, °С /° F | -25 … +50 / -13 … 122 |
| Connections & Compatibilities | |
| Mount Type | 1/4" socket |
| Supported Application | Stream Vision 2 |
| Weight & Size | |
| Body Material | Magnesium alloy |
| Dimensions, mm / inch | 197 x 140 x 72 / 7.8 x 5.5 x 2.8 |
| Weight, kg / oz | 0.95 / 34 (batteries included) |
| Operational | |
| Power Supply, V | 3.7 |
| Battery Type / Capacity / Output Voltage | Li-Ion Battery Pack APS3 / 3200 mAh / DC 3.7 V(removable) Li-Ion Battery Pack / 4000 mAh / DC 3.7 V (built-in) |
| External power supply | 5V |
| Operating Time on Battery Pack (att=22°C), h*** | 6 |
