Pulsar Telos LRF XP50 Thermal Spotter
*UK Users Only*
Powerful, Upgradeable, Handheld Thermal Spotter
The first upgradeable* thermal imaging monocular from Pulsar is the Telos LRF XP50. The Telos series offer future-proof thermal spotters that give users the option to update technical parts to keep their equipment current with cutting-edge innovations while still being reasonably priced.
Pulsar thermal imaging users will have the option of switching to more powerful optics, adding a higher resolution sensor or display, and upgrading to more effective and useful electrical components. They will even be able to add a laser sensor and more optical channels to the device, ensuring that their product is always useful and reasonably priced.
The Telos LRF XP50 thermal rangefinder monocular has a remarkable 18 mK NETD for its 640x480, 17 m, European-made Lynred sensor, which is extremely sensitive.
Even in the worst weather, this sensor quality ensures absolutely stunning, detailed thermal imaging capabilities. The fastest aperture 50mm f1.0 germanium lens gives you the clearest, most detailed, and most educational image under any lighting circumstances.
For locating an object at a larger distance, the Telos LRF is perfect. To determine distances quickly and accurately, use the integrated precision laser rangefinder. Both single measurements and continuous scanning modes of the LRF can detect distances up to 1000m.
This unit is equipped with cutting-edge Pulsar thermal imaging picture boost technology. These proprietary algorithms enable the Telos XP50's thermal imaging to achieve the highest degree of clarity, contrast, and clarity, placing it at the top of Pulsar's thermal spotters. They are excellent thermal monoculars for hunting, wildlife observation, security and thermal imaging surveys.
*This new and unique Pulsar thermal solution is currently in the development phase and will be introduced in 2024. All Telos monoculars purchased in 2023 will be eligible for the upgrade as soon as this service starts.
Find our Pulsar Comparison Tool here
Product details
Key Features
- 1800 m detection range
- Fast aperture F50/1.0 germanium lens
- Fast aperture F50/1.0 germanium lens
- Stream Vision 2. Wi-Fi integration with iOS and Android devices
- High-contrast AMOLED display
- Dual Wi-Fi waveband support 2.4 / 5 GHz
- Operation in extreme temperatures -25 to +40°C
- IPX7 submersion waterproof rated
- A selection of 8 color palettes
Specifications
Main | |
Sensor | 640x480 pix. @ 17 µm (NETD <18 mK) |
Objective lens | F50 / 1.0 |
Magnification, x | 2.5 – 10 (x4 digital zoom) |
Magnification in monocular mode / attachment mode, x | - |
Field of view (HxV), degrees / m@100m | 12.4x9.3 / 21.8x16.3 |
Detection range, m | 1800 |
Sensor | |
Type | uncooled |
Resolution, pixels | 640x480 |
Pixel pitch, µm | 17 |
NETD, mK | <18 |
Frame rate, Hz | 50 |
Optics | |
Objective lens | F50 / 1.0 |
Magnification, x | 2.5 – 10 (x4 digital zoom) |
Magnification in monocular mode / attachment mode, x | - |
Field of view (HxV), degrees / m @ 100 m | 12.4x9.3 / 21.8x16.3 |
Eye relief, mm | 14 |
Recommended magnification of the day scope, x | - |
Display | |
Type | AMOLED HD |
Resolution, pixels | 1024x768 |
Range Performance | |
Detection range, m | 1800 |
Laser Rangefinder | |
Safety class for laser equipment according to IEC 60825-1:2014 | 1 |
Wavelength, nm | 905 |
Max. measuring range, m | 1000 |
Measurement accuracy, m | ± 1 |
Video Recorder | |
Video / photo resolution, pixel | 1024x768 |
Video / photo format | .mp4 / .jpg |
Built-in memory, GB | 64 |
Built-in memory capacity | - |
Wi-Fi | |
Wireless Protocol | Wi-Fi |
Wireless Standard | IEEE 802.11 b/g/n/ac (WPA) |
Frequency, GHz | 2.4 / 5 |
Environmental Characteristics | |
Degree of protection, IP code (IEC60529) | IPХ7 (waterproof) |
Operating temperature range, °С | -25 – +40 |
Connections and Compatibilities | |
Mount, type | 1/4" |
Remote control | - |
Supported Application | Stream Vision 2 |
Power Supply | |
Output voltage, V | 3.0 – 4.2 |
Battery type | LPS 7i Li-Ion Battery Pack |
Capacity, mAh | 6400 |
Operating time on battery pack (at t=22°C), h * | 8.5 |
External power supply, V | 5V, 9V (USB Type-C Power Delivery) |
Weight & Size | |
Body material | rubber armored reinforced plastic |
Dimensions, mm | 238x72x90 |
Weight, kg | 0.58 (w/o battery) / 0.72 (with the LPS7i battery) |
