Pulsar Thermion 2 LRF XG50 Thermal Scope
Free Thermal Targets & Spare Battery
*UK Users Only*
Pulsar Thermion 2 LRF XG50 Thermal Scope
Sale price£3,999.00
Regular price
RRP (/)
Sleek Thermal Scope with Powerful Optics
The Thermion 2 LRF XG50 adds to Pulsar's impressive line of thermal scopes with laser rangefinding capabilities.
This thermion 2 thermal scope offers outstanding image clarity thanks to an extremely sensitive 640×480, 12µm, <40mK NETD thermal sensor, combined with a powerful 50mm f1.0 germanium objective lens.
The result is crystal clear, richly contrasted thermal imagery and an unrivalled detection range of up to 2300m - even in adverse conditions when thermal contrast is low, such as heavy rain, dense fog, and snow.
Find our Pulsar Comparison Tool here
Product details
Key Features
- 640×480, 12µm, <40mK NETD thermal sensor
- Fast aperture 50mm f1.0 germanium objective lens
- 2300m detection range
- Up to 10 hours of battery life
- Variable magnification
- Precision laser range finder - 800m measuring range with ± 1m accuracy
- 1024x768 HD AMOLED display
- Still image and video recorder
- Stream Vision 2 compatibility
- Picture-in-picture (PiP) mode
- 8 colour palettes
- 5 shooting profiles
- 10 zeroing profiles
- 10 electronic reticles
- High calibre recoil rated
- Mounts using 30 mm rings
- IPX7 waterproof rated
Specifications
| Main | |
| Sensor | 640x480 @ 12 µm (NETD <40 mK) |
| Objective lens | F50 F/1.0 |
| Magnification, x | 3 – 24 |
| Field of view (HxV), degrees / m@100m | 8.8x6.6 / 15.4x11.5 |
| Detection range, m | 2300 |
| Sensor | |
| Type | uncooled |
| Resolution, pixels | 640x480 |
| Pixel pitch, µm | 12 |
| NETD, mK | <40 |
| Frame rate, Hz | 50 |
| Optics | |
| Objective lens | F50 / 1.0 |
| Magnification, x | 3 – 24 |
| Field of view (HxV), degrees / m @ 100 m | 8.8x6.6 / 15.4x11.5 |
| Eye relief, mm | 50 |
| Display | |
| Type | AMOLED |
| Resolution, pixels | 1024х768 |
| Range Performance | Detection range, m |
| Detection range, m | 2300 |
| Laser Rangefinder | |
| Safety class for laser equipment according to IEC 60825-1:2014 | 1 |
| Wavelength, nm | 905 |
| Max. measuring range, m | 800 |
| Measurement accuracy, m | ± 1 |
| Reticle | |
| Click value, H/V, mm at 100 m | 15 – 3х, 7.5 – 6х, 3.75 – 12х, 1.86 – 24х |
| Click range, H/V, mm at 100 m | 3000 / 3000 |
| Number of preloaded reticles | 10 |
| Video Recorder | |
| Video / photo resolution, pixel | 1024x768 |
| Video / photo format | .mp4 / .jpg |
| Built-in memory, GB | 16 |
| Wi-Fi | |
| Wireless Protocol | Wi-Fi |
| Wireless Standard | IEEE 802.11 b/g/n/ac |
| Frequency, GHz | 2.4 / 5 |
| Environmental Characteristics | |
| Degree of protection, IP code (IEC60529) | IPX7 |
| Operating temperature range, °С | -25 – +50 |
| Connections and Compatibilities | |
| Max. recoil power on rifled weapon (Eo), Joules | 6000 |
| Shock resistance on the smooth-bore rifles, caliber | 12 |
| Compatible mounts | Standard 30 mm rings |
| Supported Application | Stream Vision 2 |
| Power Supply | |
| Output voltage, V | 3.7 |
| Battery type | Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal) |
| Capacity, mAh | 2000 (external) + 4900 (internal) |
| Operating time on battery pack (at t=22°C), h * | 9 |
| External power supply, V | 5 V, 9 V (USB Type-C Power Delivery) |
| Weight & Size | |
| Body material | Aluminum alloy |
| Dimensions, mm | 420x78.5x94.5 |
| Weight, kg | 0.97 |
